　　Other names for 3BHT300026R1:

　　Digital Input/Output Module 3BHT300026R1

　　3BHT300026R1 Input/Output Module

　　Communication Module 3BHT300026R1

　　I. Module Overview: An Industrial Powerhouse for Controlling 32-Channel Analog Signals

　　In today's wave of industrial automation, the ABB 3BHT300026R1, as a 32-channel analog input module (AI650 series), can be considered the "data hub" of the ABB AC800M control platform. Designed for demanding applications in process industries, power systems, and petrochemical plants, this module utilizes 32 channels of high-precision analog signal acquisition to accurately translate complex continuous variables such as temperature, pressure, flow rate, and liquid level into digital signals recognizable by the control system. Belonging to the ABB S600 I/O series, this module is a core component of the AC800M/800xA DCS control system and is widely adaptable to continuous control and batch processing scenarios in process industries.

　　Inheriting features from its sibling modules in the same series:

　　Model Function Positioning Number of Channels

　　3BHT300032R1 Analog Input Multi-channel AI

　　3BHT300051R1 (AO650) Analog Output Multi-channel AO

　　3BHT300025R1 (DI650) Digital Input 16-channel DI

　　3BHT300026R1 Analog Input/Output 32-channel AI/AO

　　3BHT300009R1 (DO620) Digital Output 32-channel DO

　　The 3BHT300026R1 plays a key role in this matrix, responsible for the 32 analog input channels.

　　II. Core Technical Parameters: Industrial Standards with Precision Down to the Millimeter

　　Based on the unified architecture of the ABB AC800M/S600 I/O series, the technical parameters of the 3BHT300026R1 can be precisely outlined as follows:

　　Parameter Name Specification Value

　　Order Number: 3BHT300026R1

　　Number of Channels: 32 analog channels

　　Signal Type: Voltage (0~10V / ±10V) or Current (4~20mA / 0~20mA)

　　Resolution: 12~16 bits (depending on specific configuration)

　　Conversion Accuracy: ±0.1%~±0.5% FS (full scale)

　　Input Impedance: Voltage Mode ≥10kΩ / Current Mode 250Ω

　　Channel Isolation: Inter-group isolation, isolation voltage 500V DC

　　Power Supply Voltage: DC 24V (module powered)

　　Operating Temperature: -25°C ~ +70°C (storage); horizontal installation operating temperature ≤55°C, Vertical Mounting ≤40°C

　　Protection Rating IP20 (Dustproof and Electric Shockproof)

　　Dimensions (W×H×D): 17.6mm × 56.7mm × 42.3mm (0.69" × 2.23" × 1.67")

　　Weight: Approx. 90g (0.20 lbs)

　　Communication Interface: Fiber Optic Interface (Modular Bus), compatible with CI801/CI840/CI840A

　　Certifications: CE, UL, RoHS, ATEX Zone 2 (Hazardous Area Zone 2)

　　III. Communication Architecture: The High-Speed Nerve of the Fiber Optic Bus

　　The 3BHT300026R1 adopts ABB's signature Modular Bus fiber optic bus architecture, which is its core advantage distinguishing it from ordinary analog modules.

　　The module is equipped with 10... Mbit transmitter/receiver, supporting two fiber optic topologies:

　　Simple Configuration (Ring): Fiber optic module bus nodes are connected in a ring, suitable for small to medium-sized systems;

　　Full-Duplex Configuration (Linear): Nodes are connected in a row, suitable for large-scale distributed systems.

　　Through the TB842 communication interface module, the 3BHT300026R1 can seamlessly interface with the following devices:

　　Connection Target Interface Path

　　CI801TB842 → TB806 → CI801

　　CI840/CI840ATTB842 → TU847 → CI840/CI840A

　　S800 I/O Cluster TB842 → TU846 → TB806/TB846

　　Both Plastic Fiber (POF) and Hard Silicon Fiber (HCS) are compatible, providing great flexibility for system integration.

　　IV. Module Redundancy and Hot-Swapping: Dual Guarantee of System Reliability

　　The 3BHT300026R1 inherits ABB's... The ABB I/O module family inherits a strong gene—support for module redundancy and hot-swapping. Just like the design philosophy demonstrated by the ABB DO620 (3BHT300009R1) digital output module, this analog module also supports online replacement, eliminating the need for system power interruption during maintenance and maximizing the guarantee of 24/7 continuous operation in industrial environments.

　　Its fiber optic communication architecture uses the TB842 fiber optic connector, supporting both simple ring and full-duplex configurations:

　　Simple configuration: Fiber optic module bus nodes are connected in a ring, so a failure in one node does not affect the remaining nodes;

　　Full-duplex configuration: Nodes are connected in a row, suitable for high-bandwidth applications.

　　This design is consistent with ABB's... The 3BHT300032R1 analog input module inherits the same communication architecture, ensuring stable operation in complex network topologies.

　　V. Application Scenarios: Covering the Entire Industry from Power to Chemicals

　　Process Industries

　　In petrochemical and natural gas processing scenarios, the 32-channel analog module can simultaneously acquire key parameters such as reactor temperature, pipeline pressure, and flow meter signals, allowing one module to replace multiple single-channel modules, significantly saving cabinet space and cabling costs.

　　Power Systems

　　In substation automation, the 32 analog inputs can simultaneously monitor the voltage, current, and power factor of multiple circuits. Combined with ABB's Control Builder engineering software, it enables complete control logic design under the IEC 61131-3 standard.

　　Metallurgy and Water Treatment

　　High temperature, high humidity, and strong electromagnetic interference—these harsh environments are the domain of the 3BHT300026R1. Its ATEX Zone 2 explosion-proof certification and 500V... DC channel isolation design ensures stable operation even in hazardous areas and environments with strong interference.

　　VI. Synergistic Operation with Other Modules

　　In practical engineering, the 3BHT300026R1 is often deployed in synergy with the following modules:

　　Synergistic Module Model & Value

　　Digital Input DI621 (3BHT300012R1): 16 digital inputs + 32 analog inputs = Complete signal acquisition

　　Digital Output DO620 (3BHT300009R1): 32 AI inputs + 32 DO inputs = Perfect pairing for closed-loop control

　　Analog Output AO650 (3BHT300051R1): 32 AI inputs + multiple AO inputs = Complete analog signal link

　　Taking the DI621 as an example, its 16 digital inputs combined with the 3BHT300026R1's 32 analog inputs can construct a 48-channel hybrid I/O station, working in conjunction with the ABB 800xA... The DCS system meets the needs of most medium-sized control applications.

　　VII. Engineering Configuration: Supported by Control Builder and Automation Builder

　　Seamless Integration with ABB Control Builder

　　According to ABB's official documentation, Control Builder, as the unified engineering software for the AC800M controller, supports all five programming languages of IEC 61131-3 (IL, ST, FBD, SFC, LD), and can perform complete configuration and diagnostics on the 3BHT300026R1. Engineers can read 32 channels of analog data using FROM/TO instructions or dedicated function blocks, and can also use dedicated instructions like RD3A/WR3A (for compatible models) for efficient read and write operations.

　　The module has a built-in BFM (Buffer Memory) data buffer register area, with each channel configured with an independent conversion result register, supporting online debugging functions such as status inspection, Force, and Overwrite, making on-site debugging as precise and efficient as a butcher's dissection.

　　ABB provides two powerful engineering tools for the 3BHT300026R1:

　　Control Builder (for AC800M):

　　Supports all five programming languages of IEC 61131-3 (IL, ST, FBD, SFC, LD)

　　Provides object-oriented programming for Control Modules, allowing for parameterization and multiple instantiation of entire units (such as reactors)

　　Built-in self-tuning PID controller and direct interface function blocks for frequency converters

　　Automation Builder (for AC500/CP600):

　　Based on CODESYS, a free Basic license is sufficient for initial use

　　Unified platform covering PLC, safety, drive, and motion control

　　Supports simulation debugging; logic can be verified in a virtual "Soft Controller" before downloading to hardware

　　Conclusion

　　The ABB 3BHT300026R1, with its massive 32-channel acquisition capability, 12-bit precise conversion accuracy, high-speed fiber optic bus communication, and ATEX-certified explosion-proof safety, sets a new benchmark for industrial analog signal acquisition modules. In Automation... Powered by the Builder unified platform, it's not just a hardware module, but also the most reliable bridge connecting the physical world and digital control.
